AlluGuard Roll 77 Electric Button Control Garage Door AlluGuard Aluminium Roller Garage Doors

Using the most popular size of double walled aluminium insulated slats this roller door is a robust design but very simple operation method using only a hold to run internal wall mounted control panel. Press and hold one button for open and one button for closing, that is it.

No remote controls, no infra red beams, no bottom edge safety sensors, just a simple hold to run control, ideal for when you don’t use your garage very much or the garage is entered on foot all the time and is perhaps also integral to the house. Less hassle with electronics and easier to maintain over time.

The AlluGuard ROLL 77 is constructed from high quality 77mm deep double skinned aluminium slats with a foam filled core. It is a made to measure, electric operated roller garage door as standard, made to the exact millimetre in width and height.

The door is electrically operated as standard and incorporates an internal emergency manual release in case of a power failure. This is a winding process using a winding handle provided attaching via a hook to the eye of the motor drive. This can be specified as either on the left or right as viewed from inside the garage.

The curtain of this door rolls around a steel barrel which is supported either side by steel endplates which have a dimension of 300mm x 300mm, which is the headroom required if you wish to hide the roll. Always allow for a maximum 50mm of curtain ‘hang down’ when the door is opened if the opening height is critical to you. This is the same on all roller garage doors.



Hand crank	Lined guide	ZF Lock	Barrel	safety brake
