Samson GarageGuard Garage Door Samson Steel Pedestrian Doors

The Garage Guard is a steel doorset designed to protect your garage and any other outbuildings with a steel door designed around security with various higher levels of security if required.

The standard door is 55mm thick with double skinned steel construction and Magnelis corrosion resistant steel as standard for a 10 year guarantee. U-values are available between 3.1 and 1.6 (w/m2k) depending on the infill used in the door panel. Stainless steel lever/lever handles are standard with options on other furniture.

4 dog bolts are fitted as standard on the hinge side and an Arrone AR910 DIN sashlock is also standard.

The door is purpose made to size for a perfect fit, and has an adjustable outer frame to accommodate any discrepancies in the aperture whilst fitting.

With a choice of finished colours, and even a choice of a different colour either side as well as a different sub frame colour, this door can enhance a building whilst providing security and excellent weather protection too.

The GarageGuard offers the following as standard:

> 55mm door leaf, thicker than others with a choice of infill offering up to 1.6w/m2k thermal value
> Double glazed vision panel units, maintaining thermal performance
> Hooply multibolt locking with SBD recommended TS007 3 star cylinder & escutcheon sets providing quality & secure locking
> Door leaf constructed from magnelis for industry leading corrosion resistance offering a 10 year warranty against corrosion.
> U Channel adjustment sections allowing greater tolerance in opening while also cloaking fixing points and minimising mastic gaps.
> Aluminium threshold strip/ weather bar with rain deflector for inward opening doorsets.
> 4 number stainless steel dog bolt hinges per leaf
> All doors fully CE marked with full Declaration of Performance as required by current legislation

You also get as standard:

> Hardware is already fitted to the door in the factory saving time and effort on site.
> Locks are always fitted into a purpose made internal reinforcement box not hung from the fore end plate loose into the leaf
> Self cutting frame fixings and cover caps are provided along with spare hinge screws and driver bits.
> A full fitting kit is supplied with each order including 12mm allen key to make frame adjustment easy and a selection of drills for fitting into concrete or steel.
> A pot of touch up paint
> A tube of clear mastic for use during installation to prevent water ingress under the threshold.
> 10 year anti corrosion warranty as standard.

Made to Measure

All steel doors are made to order in the UK factory, they are available in a wide range of heights and widths to suit any requirement, and are delivered fully assembled.

Sizes and Frames:

600mm - 1350mm wide
1860mm - 2800mm high

95mm single rebate C frame

Security Upgrades

If the application requires additional security measures, we can get the GarageGuard equipped with an official RC1, RC2 or RC3 security upgrade.

Choice of window options:

Choose from either a flat finish or the traditional look from vertical groove design.

Polyester powder coated as standard in one of 50 colours available and three timber woodgrain effects (extra charge) or a special RAL or BS (extra charge).

Also available in stainless steel, with brushed, polished and patterned finishes. Alternatively, the external doors are available unfinished for site finishing.

 Standard PPC Colour Range
